| Model |
6CX-ETE |
| Configuration |
4 Stroke, Vertical, Water Cooled Diesel Engine |
| Number of Cylinders |
6 In-line |
| Bore x Stroke |
4.33" x 4.92" (110mm x 125mm) |
| Displacement |
435" (7.127 L) |
| Continuous Rating Output at Flywheel |
375 HP/2600 rpm
(275.8 kW/2600 rpm) |
| Maximum Output at Flywheel |
420 HP/2700 rpm
(308.9kW/2700 rpm) |
| Combustion System |
Direct Injection |
| Aspiration |
Turbocharged with Intercooler |
| Starting System |
Electric Starting
(DC 12V, 4kW Starting Motor/12V 55A Alternator) |
| Cooling System |
Fresh Water Cooling by Centrifugal Fresh-Water Pump and
Rubber Impeller Seawater Pump |
| Lubrication System |
Forced Lubrication |
| Rotation |
Bi-rotation (Clockwise/Counter Clockwise) |
| Dry Weight |
820 kg (1808 lbs.) |
